Schneider Electric Easy9 RCCB | 2 Pole, 63A, 30mA (AC Type) | Instantaneous Earth Leakage & Human Protection | High-Capacity Circuit Safety (EZ9R35263)

Ensure the highest level of electrical safety and protect lives in your home or commercial space with the Schneider Electric Easy9 Residual Current Circuit Breaker (RCCB). This robust 2-pole, 63A RCCB is engineered to provide instantaneous earth leakage protection at a critical 30mA (AC type), making it indispensable for safeguarding individuals from electric shocks and preventing electrical fires caused by insulation faults, especially in higher-load circuits. Rely on Schneider Electric's established reputation for quality and innovation for uncompromising safety.

Key Features & Benefits:

• Superior Life Safety Protection: Instantly cuts off power at a dangerous 30mA earth-leakage current, offering crucial protection against electric shock and mitigating fire risks caused by ground faults.
• Reliable AC Type for General Use: Specifically designed to detect alternating sinusoidal residual currents, making it universally suitable for a wide range of standard electrical installations and appliance protection.
• High Breaking Capacity (630A): Ensures effective and safe interruption of substantial fault currents with an enhanced rated breaking and making capacity of 630A.
• Built for Durability: Constructed for exceptional endurance with 5000 mechanical cycles and 4000 electrical cycles, promising dependable operation for many years.
• Effortless DIN Rail Installation: Features a convenient clip-on mounting mechanism for quick and secure attachment to standard DIN rails within your distribution board.
• Flexible Wiring Options: Equipped with robust tunnel type terminals (top or bottom) that accommodate both rigid (1-35mm²) and flexible (1-25mm²) cables for adaptable and secure connections.
• Clear Contact Position Indicator: Provides an immediate visual indication of the breaker's current operational status (ON/OFF) for quick diagnostics.
• Voltage Independent Tripping: Maintains consistent and reliable protection by tripping effectively even during fluctuations in the main voltage supply, ensuring continuous safety.
• Compact & Space-Efficient: Its slim 36mm width (2-pole) optimizes space within your electrical panel, contributing to a tidy and organized installation.
• Certified for Safety & Compliance: Compliant with IEC 61008-1 and IS 12640-1 standards, and proudly carries CE and ISI certifications, guaranteeing adherence to stringent safety and quality regulations for the Indian market.

Technical Specifications:

• Brand: Schneider Electric
• Range: Easy9
• Product Type: Residual Current Circuit Breaker (RCCB)
• Model Number: EZ9R35263
• Poles: 2P (2 Pole)
• Neutral Position: Left
• Rated Current (In): 63 A
• Network Type: AC
• Earth-Leakage Sensitivity: 30 mA
• Earth-Leakage Protection Time Delay: Instantaneous
• Earth-Leakage Protection Class: Type AC
• Rated Breaking & Making Capacity: 630 A
• Rated Conditional Short-Circuit Current: 3000 A (at 63A)
• Rated Operational Voltage (Ue): 240 V AC 50 Hz
• Rated Insulation Voltage (Ui): 440 V AC
• Rated Impulse Withstand Voltage (Uimp): 4 kV
• Control Type: Toggle
• Mounting Mode: Clip-on
• Mounting Support: DIN rail
• Connection Terminals: Tunnel type terminal (top or bottom)
  • 1…35 mm² rigid cable
  • 1…25 mm² flexible cable
• Dimensions (H x W x D): 82 mm x 36 mm x 77.5 mm
• Product Weight: 0.235 kg
• Colour: Grey (RAL 7035)
• Mechanical Durability: 5000 cycles
• Electrical Durability: 4000 cycles (at 240 V AC 50 Hz)
• Standards: IEC 61008-1, IS 12640-1
• Certifications: ISI, CE
• IP Degree of Protection: IP20
• Ambient Air Temperature for Operation: -5…55 °C
• Targeted Country: India
