Schneider Electric Easy9 RCCB | 2 Pole, 40A, 100mA (AC Type) | Instantaneous Earth Leakage & Enhanced Fire Protection | Reliable Circuit Safety (EZ9R55240)

Reinforce the safety of your electrical installations with the Schneider Electric Easy9 Residual Current Circuit Breaker (RCCB). This robust 2-pole, 40A RCCB provides instantaneous earth leakage protection at 100mA (AC type), making it an excellent choice for general circuit protection, fire safety, and protection of equipment from ground faults in residential, commercial, and light industrial environments. Rely on Schneider Electric's proven quality for dependable electrical protection.

Key Features & Benefits:

• Enhanced Fault Protection: Instantly disconnects power at 100mA earth-leakage current, significantly reducing the risk of electrical fires and protecting valuable equipment from damaging ground faults.
• Reliable AC Type for General Use: Specifically designed to detect alternating sinusoidal residual currents, making it universally suitable for a wide range of standard electrical appliances and circuits.
• High Breaking Capacity: Ensures effective and safe interruption of fault currents with a strong rated breaking and making capacity of 500A.
• Durable & Long-Lasting: Constructed for exceptional endurance with 5000 mechanical cycles and 4000 electrical cycles, promising reliable operation for many years.
• Effortless DIN Rail Installation: Features a convenient clip-on mounting mechanism for quick and secure attachment to standard DIN rails within your distribution board.
• Versatile Wiring: Equipped with tunnel type terminals (top or bottom) that accommodate both rigid (1-35mm²) and flexible (1-25mm²) cables for adaptable connections.
• Clear Contact Position Indicator: Provides an immediate visual indication of the breaker's current operational status (ON/OFF).
• Voltage Independent Tripping: Maintains consistent and reliable protection by tripping effectively even during fluctuations in the main voltage supply.
• Compact Design: Its slim 36mm width (2-pole) optimizes space within your electrical panel, ensuring a tidy installation.
• Certified for India: Compliant with IEC 61008-1 and IS 12640-1 standards, and proudly carries CE and ISI certifications, guaranteeing compliance and safety for the Indian market.

Technical Specifications:

• Brand: Schneider Electric
• Range: Easy9
• Product Type: Residual Current Circuit Breaker (RCCB)
• Model Number: EZ9R55240
• Poles: 2P (2 Pole)
• Neutral Position: Left
• Rated Current (In): 40 A
• Network Type: AC
• Earth-Leakage Sensitivity: 100 mA
• Earth-Leakage Protection Time Delay: Instantaneous
• Earth-Leakage Protection Class: Type AC
• Rated Breaking & Making Capacity: 500 A
• Rated Conditional Short-Circuit Current: 3000 A (at 40A)
• Rated Operational Voltage (Ue): 240 V AC 50 Hz
• Rated Insulation Voltage (Ui): 440 V AC
• Rated Impulse Withstand Voltage (Uimp): 4 kV
• Control Type: Toggle
• Mounting Mode: Clip-on
• Mounting Support: DIN rail
• Connection Terminals: Tunnel type terminal (top or bottom)
  • 1…35 mm² rigid cable
  • 1…25 mm² flexible cable
• Dimensions (H x W x D): 82 mm x 36 mm x 77.5 mm
• Product Weight: 0.235 kg
• Colour: Grey (RAL 7035)
• Mechanical Durability: 5000 cycles
• Electrical Durability: 4000 cycles (at 240 V AC 50 Hz)
• Standards: IEC 61008-1, IS 12640-1
• Certifications: CE, ISI
• IP Degree of Protection: IP20
• Ambient Air Temperature for Operation: -5…55 °C
• Targeted Country: India

Secure your electrical installations against critical fault currents and enhance fire protection. Add the Schneider Electric Easy9 2P 40A 100mA AC Type RCCB to your cart today for ultimate peace of mind!
