Schneider Electric Easy9 RCCB | 2 Pole, 25A, 30mA (AC Type) | Instantaneous Earth Leakage Protection | Reliable Safety for Home & Residential Electrical Circuits (EZ9R35225)

Ensure superior electrical safety in your home and protect against hazardous electric shocks with the Schneider Electric Easy9 Residual Current Circuit Breaker (RCCB). Designed for reliable performance in residential and commercial applications, this 2-pole, 25A RCCB provides instantaneous earth leakage protection at 30mA (AC type), safeguarding lives and preventing equipment damage from fault currents. Trust in Schneider Electric's legacy of quality and safety.

Key Features & Benefits:

• Life-Saving Earth Leakage Protection: Instantly disconnects power at 30mA earth-leakage current, crucial for protecting individuals from electric shock and preventing electrical fires.
• Reliable AC Type Protection: Specifically designed for detecting alternating sinusoidal residual currents, making it ideal for most standard household appliances and circuits.
• High Breaking Capacity: Offers a robust rated breaking and making capacity of 500A, ensuring effective fault interruption.
• Robust & Durable: Built for longevity with 5000 mechanical cycles and 4000 electrical cycles, ensuring years of dependable operation.
• Easy & Secure Installation: Features a clip-on design for quick mounting on standard DIN rails. Tunnel type terminals accommodate both rigid (1-35mm²) and flexible (1-25mm²) cables for versatile wiring.
• Clear Status Indication: A contact position indicator provides a clear visual confirmation of the breaker's status.
• Voltage Independent Operation: Ensures tripping even under voltage fluctuations, providing consistent protection.
• Compact & Space-Saving: With a width of just 36mm, its 2-pole design fits efficiently in your distribution board.
• Certified for India: Compliant with IS 12640-1 and IEC 61008-1 standards, and carries CE and ISI certifications for assured quality and safety in India.

Technical Specifications:

• Brand: Schneider Electric
• Range: Easy9
• Product Type: Residual Current Circuit Breaker (RCCB)
• Model Number: EZ9R35225
• Poles: 2P (2 Pole)
• Neutral Position: Left
• Rated Current (In): 25 A
• Network Type: AC
• Earth-Leakage Sensitivity: 30 mA
• Earth-Leakage Protection Time Delay: Instantaneous
• Earth-Leakage Protection Class: Type AC
• Rated Breaking & Making Capacity: 500 A
• Rated Conditional Short-Circuit Current: 3000 A
• Rated Operational Voltage (Ue): 240 V AC 50 Hz
• Rated Insulation Voltage (Ui): 440 V AC
• Rated Impulse Withstand Voltage (Uimp): 4 kV
• Control Type: Toggle
• Mounting Mode: Clip-on
• Mounting Support: DIN rail
• Connection Terminals: Tunnel type terminal (top or bottom)
  • 1…35 mm² rigid cable
  • 1…25 mm² flexible cable
• Dimensions (H x W x D): 82 mm x 36 mm x 77.5 mm
• Product Weight: 0.235 kg
• Colour: Grey (RAL 7035)
• Standards: IS 12640-1, IEC 61008-1
• Certifications: CE, ISI
• IP Degree of Protection: IP20
• Ambient Air Temperature for Operation: -5…55 °C
• Targeted Country: India

Protect your loved ones and your electrical system with confidence. Add the Schneider Electric Easy9 2P 25A 30mA AC Type RCCB to your cart today!
