Schneider Electric Easy9 RCCB | 2 Pole, 25A, 100mA (AC Type) | Instantaneous Earth Leakage Protection | Enhanced Safety for Home & Residential Electrical Circuits (EZ9R55225)

Fortify your electrical system against potential hazards with the Schneider Electric Easy9 Residual Current Circuit Breaker (RCCB). This 2-pole, 25A RCCB provides robust and instantaneous earth leakage protection at 100mA (AC type), often used as a main incomer protection or for applications where a higher sensitivity isn't required for direct human protection but fire safety is paramount. Rely on Schneider Electric's proven quality for dependable circuit safety.

Key Features & Benefits:

• Robust Earth Leakage Protection: Instantly disconnects power at 100mA earth-leakage current, providing essential protection against electrical fires and indirect contact risks.
• Reliable AC Type for Standard Circuits: Specifically designed to detect alternating sinusoidal residual currents, suitable for a wide range of common household and residential electrical applications.
• High Breaking Capacity: Ensures effective fault interruption with a rated breaking and making capacity of 500A.
• Durable & Long-Lasting: Engineered for endurance with 5000 mechanical cycles and 4000 electrical cycles, guaranteeing extended operational life.
• Effortless DIN Rail Installation: Features a convenient clip-on mounting for quick and secure attachment to standard DIN rails.
• Versatile Wiring: Tunnel type terminals at the top or bottom accommodate both rigid (1-35mm²) and flexible (1-25mm²) cables.
• Clear Contact Position Indicator: Provides immediate visual confirmation of the breaker's operational status.
• Voltage Independent Tripping: Maintains consistent protection by tripping effectively even during voltage variations.
• Compact Design: Its 36mm width (2-pole) allows for efficient use of space within your electrical distribution board.
• Certified for India: Compliant with IS 12640-1 and IEC 61008-1 standards, and holds ISI and CE certifications, affirming its quality and safety for the Indian market.

Technical Specifications:

• Brand: Schneider Electric
• Range: Easy9
• Product Type: Residual Current Circuit Breaker (RCCB)
• Model Number: EZ9R55225
• Poles: 2P (2 Pole)
• Neutral Position: Left
• Rated Current (In): 25 A
• Network Type: AC
• Earth-Leakage Sensitivity: 100 mA
• Earth-Leakage Protection Time Delay: Instantaneous
• Earth-Leakage Protection Class: Type AC
• Rated Breaking & Making Capacity: 500 A
• Rated Conditional Short-Circuit Current: 3000 A
• Rated Operational Voltage (Ue): 240 V AC 50 Hz
• Rated Insulation Voltage (Ui): 440 V AC
• Rated Impulse Withstand Voltage (Uimp): 4 kV
• Control Type: Toggle
• Mounting Mode: Clip-on
• Mounting Support: DIN rail
• Connection Terminals: Tunnel type terminal (top or bottom)
  • 1…35 mm² rigid cable
  • 1…25 mm² flexible cable
• Dimensions (H x W x D): 82 mm x 36 mm x 77.5 mm
• Product Weight: 0.217 kg
• Colour: Grey (RAL 7035)
• Standards: IS 12640-1, IEC 61008-1
• Certifications: ISI, CE
• IP Degree of Protection: IP20
• Ambient Air Temperature for Operation: -5…55 °C
• Targeted Country: India

Enhance your electrical safety and protect your property. Add the Schneider Electric Easy9 2P 25A 100mA AC Type RCCB to your cart today!
