Schneider Electric Easy9 RCCB | 2 Pole, 25A, 300mA (AC Type) | Instantaneous Earth Leakage & Fire Protection | Reliable Electrical Safety (EZ9R65225)

Provide robust electrical safety and fire protection for your property with the Schneider Electric Easy9 Residual Current Circuit Breaker (RCCB). This 2-pole, 25A RCCB delivers powerful and instantaneous earth leakage protection at 300mA (AC type). Ideal for main incomer protection in residential, commercial, or light industrial settings, it helps prevent electrical fires and protects equipment from major fault currents. Trust in Schneider Electric's legacy of uncompromising quality and safety.

Key Features & Benefits:

• Reliable Earth Leakage Protection: Instantly disconnects power at 300mA earth-leakage current, significantly reducing the risk of electrical fires and protecting equipment from damaging ground faults.
• AC Type for General Applications: Designed to detect alternating sinusoidal residual currents, making it suitable for a wide range of standard electrical installations and appliance protection.
• High Breaking Capacity: Ensures effective and safe interruption of fault currents with a rated breaking and making capacity of 500A.
• Built for Durability: Engineered for long-term performance with 5000 mechanical cycles and 4000 electrical cycles, promising reliable operation for years.
• Effortless DIN Rail Installation: Features a convenient clip-on mounting mechanism for quick and secure attachment to standard DIN rails in your distribution board.
• Flexible Wiring: Equipped with tunnel type terminals (top or bottom) that accommodate both rigid (1-35mm²) and flexible (1-25mm²) cables for ease of connection.
• Clear Contact Position Indicator: Provides an immediate visual indication of the breaker's current operational status.
• Voltage Independent Tripping: Ensures consistent and reliable protection by tripping effectively even during fluctuations in voltage.
• Compact & Space-Saving: Its slim 36mm width (2-pole) optimizes space within your electrical panel.
• Certified for Safety: Compliant with IEC 61008-1 and IS 12640-1 standards, and proudly carries CE and ISI certifications, guaranteeing compliance and safety for the Indian market.

Technical Specifications:

• Brand: Schneider Electric
• Range: Easy9
• Product Type: Residual Current Circuit Breaker (RCCB)
• Model Number: EZ9R65225
• Poles: 2P (2 Pole)
• Neutral Position: Left
• Rated Current (In): 25 A
• Network Type: AC
• Earth-Leakage Sensitivity: 300 mA
• Earth-Leakage Protection Time Delay: Instantaneous
• Earth-Leakage Protection Class: Type AC
• Rated Breaking & Making Capacity: 500 A
• Rated Conditional Short-Circuit Current: 3000 A
• Rated Operational Voltage (Ue): 240 V AC 50 Hz
• Rated Insulation Voltage (Ui): 440 V AC
• Rated Impulse Withstand Voltage (Uimp): 4 kV
• Control Type: Toggle
• Mounting Mode: Clip-on
• Mounting Support: DIN rail
• Connection Terminals: Tunnel type terminal (top or bottom)
  • 1…35 mm² rigid cable
  • 1…25 mm² flexible cable
• Dimensions (H x W x D): 82 mm x 36 mm x 77.5 mm
• Product Weight: 0.207 kg
• Colour: Grey (RAL 7035)
• Standards: IEC 61008-1, IS 12640-1
• Certifications: CE, ISI
• IP Degree of Protection: IP20
• Ambient Air Temperature for Operation: -5…55 °C
• Targeted Country: India

Secure your electrical installations against critical fault currents. Add the Schneider Electric Easy9 2P 25A 300mA AC Type RCCB to your cart today for ultimate peace of mind!
